2026 Kawasaki MULE PRO-FX 820 Timberline Green

Overview
The MULE PRO-FX 820 side by side is a powerful, high-capacity, three-passenger vehicle that's as durable as your days are long. With excellent performance for both work and play, it's the perfect work companion with all-day comfort and strong, dependable performance.

FEATURING:

  • Roomy cabin with 3-passenger seating
  • 812cc, 3-cylinder, 4-stroke engine
  • 1-ton (907 kg [2,000 lb]) towing capacity
  • Independent front and rear suspension

ADDITIONAL VEHICLE FEATURES:

  • Massive 1.9 m² (20 sq ft) cargo bed
  • Continuously Variable Transmission (CVT)
  • Electrically selectable 2WD/4WD, dual-mode rear differential
  • Speed-sensitive Electric Power Steering (EPS)
Specifications
Model
MULE
Category Name
UTV - Side x Side
Year
2026
Sale Type
New
Manufacturer
Kawasaki
Color
Timberline Green
power
Engine
812cc, liquid-cooled, 4-stroke, DOHC 4-valve-per-cylinder, in-line 3-cylinder
Ignition
Battery & coil
Starting
Electric
Final_Drive
2WD/4WD, shaft, dual-mode differential
Fuel_System
Fuel injection: ø34 mm x 1
Lubrication
Forced lubrication, wet sump
Transmission
Dual range (high/low) CVT with reverse
Bore_x_Stroke
72.0 x 66.5 mm
Compression_Ratio
9.5:1
performance
Frame
Ladder type, tubular steel
Steering
Rack and pinion with Electric Power Steering
Rear_Tire
26 x 11.00R12 4PR
Front_Tire
26 x 9.00R12 4PR
Rear_Brake
Dual ø212 mm discs with single-piston calipers
Front_Brakes
Dual ø212 mm discs with two-piston calipers
Rake_/_Trail
4.4° / -
Parking_Brake
Dual discs (mechanical)
Steering_Angle_(L/R)
40° (IN) / 31° (OUT), 40° (IN) / 31° (OUT)
Rear_Suspension_/_Wheel_Travel
Double wishbone / 217 mm (8.5 in) left, 220 mm (8.7 in) right
Front_Suspension_/_Wheel_Travel
Double wishbone / 222 mm (8.7 in)
details
Lighting
2x halogen
Warranty
36 months
Wheelbase
2,345 mm (92.3 in)
Seat_Height
885 mm (34.8 in)
Tread_(F/R)
1,385 mm (54.5 in) / 1,315 mm (51.8 in)
Curb_Weight*
840 kg (1,852 lb)
Fuel_Capacity
30 litres
Road_Clearance
265 mm (10.4 in)
Turning_Radius
4.8 m (15.7 ft)
Instrumentation
Multi-function display includes driving mode (2WD/4WD) indicator, digital speedometer, digital fuel gauge, clock, odometer, dual trip meters, hour meter, and various warning lamps
Towing_Capacity
907 kg (2,000 lb)
Seating_Capacity
3
Cargo_Bed_Capacity
453 kg (1,000 lb)
Vehicle_Load_Capacity
717 kg (1,581 lb)
Dimensions_(L_x_W_x_H)
3,385 x 1,625 x 1,965 mm (133.3 x 64.0 x 77.4 in)
Estimated_Dry_Weight**
803 kg (1,770 lb)
Kawasaki_Protection_Plus
12 / 24 / 36 / 48 months
Cargo_Bed_Dimensions_(LxWxH)
1,375 x 1,355 x 280 mm (54.1 x 53.3 x 11.0 in)
